| Packing Range |
10 gm to 1 kg |
| Filling System |
Multi Head Weigher (10 Head & 14 Head Weigher) |
| Filling Accuracy |
± 0.1% |
| Sealing Type |
Center Seal |
| Film Size |
Width: 100 mm – 500 mm, Length: 100 mm – 360 mm |
| Film Roll Type |
Laminated Film & Aluminum Foil Supported |
| Production Speed |
45 – 60 Bags per Minute* |
| Power Requirement |
3 kW, 230V AC, Single Phase, 50 Hz |
| Machine Dimensions |
72″ × 85″ × 126″ |
| Machine Weight |
Approx. 1400 kg |
| Wooden Case Dimensions |
1300 mm × 1000 mm × 1000 mm |
| Compressed Air Requirement |
6 CFM @ 6 Bar |
| Optional Feature |
Batch Coding Device |
